The Atlas Copco GA30-37VSDiPM air compressor redefines industrial efficiency with its permanent magnet (PM) motor and intelligent variable speed drive (VSDi) technology.
Atlas Copco has officially launched its new generation GA30-37VSDiPM series air compressors. The design of exquisite drive and intelligent control makes it energy-saving, reliable and intelligent at the same time:
- Energy saving: Pressure 4-13bar, flow 15%-100% adjustable, average energy saving 35%.
- Reliable: The driving system is waterproof and dust-proof to protect the compression system from lasting and stable operation.
- Intelligence: Self-diagnosis, self-protection, less worry and more peace of mind.
At the same time, GA30-37VSDiPM series air compressor adopts oil-cooled permanent magnet frequency conversion motor. Oil-cooled motor with horizontal design has significant advantages compared with common air-cooled permanent magnet motors on the market:
- Oil – cooled permanent magnet motor (iPM), high efficiency level up to IE4
- Direct drive, no transmission loss, higher transmission efficiency
- Efficient oil and gas separator design, oil content is less than 3PPM, longer maintenance cycle
- Independent electric control cabinet design, the whole series through EMC certification, to protect your electrical safety
- Efficient cooling system, the outlet temperature rise is controlled within 7 degrees Celsius
- Innovative cooling system, just install and remove a screw for easy cleaning
For users whose gas consumption fluctuates, Atlas Copco strongly recommends the new GA30-37VSD series air compressor, which perfectly matches the changes in air demand of customers through the motor’s variable speed, providing guarantee for efficient, reliable and energy-saving gas consumption of customers.
Contents
Atlas Copco FF full performance unit is recommended
Compared with the traditional configuration of the cold dryer, the use of Atlas built-in cold dryer has the following advantages:
- Reduce floor space and save space
- Simple installation, no external connection pipe
- Save installation costs
- Reduced air flow resistance
- Improved unit efficiency
- Easy to operate, built-in set compressor
- Integrated with the control system of the cold and dry machine
- Dry air can be output at the press of the start button
Joint control energy saving solution:
As a large energy consumer, compressors are a key factor in plant energy conservation. Based on actual measurements, each 1 bar (14.5 psi) reduction in working pressure can save 7% of energy and 3% of leakage. Multiple machines through the joint control system can reduce the pressure fluctuation of the entire pipe network system, so as to ensure that the entire system is in the best and most economical operation state.
*ES6i
The Atlas Copco controller is equipped with ES6i energy saving control system as standard, which can be controlled by up to 6 machines without additional hardware.
*Optimizer 4.0 control system
The Atlas Copco Optimizer 4.0 control system is available for joint control of more than 6 machines. At the same time, Optimizer 4.0 automatically selects the best compressor operation combination according to the actual gas consumption of the user, and makes the operation time of each compressor as much as possible. Optimizer 4.0 minimizes exhaust pressure fluctuations in the compressed air network (0.2 to 0.5 bar) compared to multiple compressors controlled by a stepped pressure band.
We are a professional Atlas Copco exporter based in China, equipped with a well-managed warehouse and a specialized maintenance team that regularly travels for machine servicing. Whether domestic or international, we ensure timely maintenance and repairs, giving our clients peace of mind when working with us. After 20 years of experience, we have developed a unique perspective on the air compressor industry. We welcome friends from around the world to visit our offices, where we will be delighted to show them our best side and strengthen our global partnerships.
Let us be your trusted partner in achieving greater efficiency and savings in your compressed air systems.
For more information or assistance, please contact us directly. We’re happy to help you find the best air solutions for your business.
Thank you for choosing Atlas Copco!
